358 Anti-Climb Fence Unmatched Security Fencing

Mesh Panel Height: 1.8m-5m
Accessory: Clips, Flat Bar, Barbed Wire, Razor Wire Fence
Application: Security Fence
Pressure Treated Wood Type: Heat Treated
Fittings: Spider Clamp + Flat Bar
Post Length: 2400mm, 2600mm, 2800mm, 3200mm, 3800mm
Wire Thickness: 3.0/4.0mm, 4.0/4.0mm
Transport Package: In Roll, Water Proof Paper Inside and Outside With
Trademark: BMP
Origin: China
HS Code: 73144900
Production Capacity: 10,000 pieces/Year
Price: $18.27 - $48.00 per meter

8615690482714 info@clear-view-fencing.co.za

Description

The 358 anti-climb fence, also known as a high-security wire fence, is the ultimate strong welded mesh panel. It offers top security with excellent visibility. The fence's design stops fingers and toes from getting through because of its tight mesh spacing of 75mm x 12.5mm. Our 358 security fence is perfect as a guarded fence system due to its thickness, resistance to cutting, and sturdy framework. It's tough to dismantle. Clients enjoy great safety and peace of mind with the high level of protection our top-quality anti-climb fence provides.

Production Process

0fd74d24e856e8b79d1420635e1da896

523a1c6601ecade79086961813225de3

Panels:

Galvanized Wire: We cut wires to size first.
Welding: A fully-automated spot welding machine welds the wires into panels.
Finishing: We then powder paint the panels for durability and corrosion resistance.

Posts for 358 Anti-Climb Fence:

HDG Tube: We cut tubes to precise measurements.
Finishing: We powder paint the posts to boost their longevity and look.

Installation of 358 Anti-Climb Fence

Type A (Square Post): We install this with multangular climbs, screws, and nuts.
Type B (Square Post with Metal Lath): This type includes multangular climbs, metal lath, screws, and nuts.
Type C (H Post): We use angle iron, crimps, screws, and nuts for this setup.

Applications

The 358 anti-climb fence is ideal for many places, including:

Key Features and Benefits 358 anti-climb fence

No Climbing Aids: The fence has no climbing aids, boosting perimeter security.
Welded Joints: We weld every intersection of the panel wires to ensure rigidity and durability.
Resistance to Tools: The tight mesh design stops attacks by both hand and powered tools.
High Visibility: The clear view through the 358 weld mesh is perfect for surveillance, especially with CCTV systems.
Difficult to Breach: It's hard to cut the mesh with standard bolt croppers.
Adaptability: We can step the fence to fit uneven ground, ensuring a secure fit.
Tamper-Resistant: We equip the fence with tamper-resistant fasteners for extra security.

Specification 358 anti-climb fence

Panel Height	Pane Width	Vertical Wire	Horizontal Wire	Posts Section	Post Length	No of Bends	No. of Clamps
1800	2515	4.00mm	3.15mm	60 x 60 x2mm	2400mm	4	16
2000	2515	4.00mm	3.15mm	60 x 60 x 2mm	2600mm	4	16
2200	2515	4.00mm	3.15mm	60 x 60 x 2mm	2800mm	4	16
2400	2515	4.00mm	3.15mm	60 x 60 x 2mm	3000mm	4	16
3000	2200	4.00mm	3.15mm	60 x 60 x 2mm	3600mm	5	20

20230328093500734

20230328093501580

20230328093503621

Packing & Loading

1> There is a piece of plastic film(with tiny bubbles); the first panel can be prevented from damaging the metal pallet
2>Metal plate is fixed at each corner of the panels, keeping the panels together and immovable.
3> there is a plastic film between two fence panels, which will prevent the friction and collision of each fence panel.
4> The wood plate on the358 anti-climb fence panels can prevent the last panel from being damaged by the top pallet

Efficient Packing and Loading Strategies for 358 Fence Systems

The 358 fence, known for its robustness and high security, requires meticulous handling to ensure its integrity during transportation. Manufacturers use a systematic approach to packing and loading these fences, as detailed in the following overview.

Packing Process:

Initial Preparation: We first clean and inspect the 358 fence panels for any defects. Then, we wrap each panel individually in a protective plastic film to protect against moisture and dust. This crucial first layer helps preserve the fence's structural and aesthetic qualities during transit.
Bundling: Next, we carefully align and stack the wrapped panels. We secure these stacks with metal bands or straps to maintain the bundle's stability. This method keeps the panels from moving and prevents potential damage, especially during long transports.
Accessory Packing: We pack essential components such as clips, nuts, and bolts separately. As shown in the image, we place these smaller items in sturdy boxes to prevent loss and damage. We clearly label each box with its contents and handling instructions to make identification and proper handling easier.
Final Packaging: For the final step, we place the wrapped and bundled fence panels and accessory boxes onto wooden pallets. We then wrap these pallets again in heavy-duty plastic or shrink wrap, which enhances stability and adds another layer of protection against the elements.

358 anti-climb fence Loading Process:

Container Preparation: Before loading, the interior of the container is inspected to ensure it is dry and clean. This step is vital to prevent any moisture-related damages that could compromise the fence's quality.
Strategic Loading: Using a forklift, each pallet is carefully loaded into the container. The placement is strategic, maximizing space while ensuring each pallet is accessible for unloading. The heavier pallets are placed at the bottom to create a stable base.
Securing the Load: Once all items are loaded, they are secured with cargo straps and braces within the container. This precaution prevents any shifting during transportation, a common cause of damage when transporting large items such as fencing.
Sealing and Marking: After the container is fully loaded, it is sealed, and the seal numbers are recorded. The container is also marked with identification numbers and handling symbols, providing all necessary information for safe and efficient transit.
