Razor Wire

Home / Razor Wire / BTO 12 Razor Wire

BTO 12 Razor Wire

  • Blade thickness: 0.5 ± 0.05 mm
  • Blade length: 12 ± 1 mm
  • Blade width: 15 ± 1 mm
  • Blade spacing: 26 ± 1 mm
  • Core wire diameter: 2.5 ± 0.1 mm
  • Coil outer diameters: 450–980 mm
  • Loops: 56 per coil (cross type)
  • Extended length: 8–16 m
  • Clips: 3 or 5, per coil size
  • Blade series: BTO
  • HS code: 7313000000
  • BMP price (FOB): USD 1.25/m
Inquiry Now
Description

BMP engineers BTO 12 Razor Wire for sites that demand the toughest perimeter defense. The 0.5 mm thick steel blades measure 12 mm in length and 15 mm in width, sit 26 mm apart, and wrap a 2.5 mm diameter core. These sharp edges stop intruders fast and raise any fence’s anti-climb score.

Quick Snapshot

  • Core wire: heavy or normal galvanized, or stainless steel
  • Blade: heavy galvanized, galvanized, or stainless steel
  • Coil styles: single or cross, 450–980 mm diameters
  • Markets: Europe, MENA, UK, Americas, South & Central Africa, APAC

Detailed BTO 12 Razor Wire Structure & Composition

BMP uses high-tensile steel wire that resists stretching, cutting, and corrosion. We crimp razor-sharp steel strips around the core, then form tight coils that you clip together in seconds. The result: a stable, solid, and fearsome barrier.

Materials & Coatings

Component Heavy Galvanized Galvanized Stainless Steel
Blade ✔︎ ✔︎ ✔︎
Core Wire ✔︎ ✔︎ ✔︎

 BTO 12 Razor Wire Specifications Table

Item Data
Blade series BTO (Barbed Tape Obstacle)
Blade type BTO 12
Blade thickness (mm) 0.5 ± 0.05
Blade length (mm) 12 ± 1
Blade width (mm) 15 ± 1
Blade spacing (mm) 26 ± 1
Core wire Ø (mm) 2.5 ± 0.1
Coil ODs (mm) 450 / 500 / 600 / 700 / 800 / 900 / 980
Loops per coil 56 (cross)
Extended length (m) 8–16, based on OD
Clip count 3 (≤ 600 mm OD)
HS code 7313000000
Price (FOB Tianjin) USD 1.25 per meter (May 2025 offer)

Key Benefits of BTO 12 Razor Wire

  • Maximum deterrence: Intruders meet sharp blades that slice clothing and gear.
  • Long service life: Heavy zinc or stainless finishes shrug off rust, even in desert or coastal air.
  • Fast installation: Two workers clip 100 m in under one hour—no heavy machines.
  • Scalable security: Choose coil sizes and clip counts to match risk level.
  • Cost-efficient: Stronger and longer-lasting than traditional barbed wire, yet priced competitively.

Applications of BTO 12 Razor Wire

Sector Typical Setup
Prisons Triple-row fence-top coils
Military bases Ground obstacles plus fence-top coils
Airports CBT 65 + BTO 12 combo on perimeter fences
Refineries Single 700 mm cross coils on wall crowns
Power stations 500 mm coils fixed to palisade fences
Temporary sites Mobile concertina barriers
Farms & ranches 450 mm single coils on posts

Packaging & Delivery for BTO 12 Razor Wire

BMP binds coils with plastic film, straps them on wooden pallets, and seals each stack with moisture-proof wrap. A 20-foot container fits:

  • 45 rolls at 700 mm OD, cross type
  • Gross weight: 18.5 t

We ship FOB Tianjin or CFR worldwide ports in 7 days after deposit.

Conditions to Consider Before Installing

  • Local law: Confirm razor wire legality in your country or city.
  • Climate: Pick stainless steel for marine or chemical zones.
  • Support strength: Use sturdy posts—coils pull with high tension.
  • Safety gear: Wear cut-resistant gloves, goggles, and sleeves.
  • Clear zones: Keep 500 mm clearance on both sides to avoid accidental contact.
  • Maintenance plan: Inspect clips and tension every 6 months.

Customer Feedback on BTO 12 Razor Wire — Qatar

“BMP delivered exactly on schedule. Workers installed 600 m of BTO 12 Razor Wire around our logistics yard in Doha. The blades look intimidating, and no trespasser has dared to test the fence since. We rate the product 10/10.” — Mr. Fahad A., Project Manager

❓ FAQs on BTO 12 Razor Wire

Q1: Can I mix BTO 12 with CBT 65 in one fence?
A1: Yes. Place CBT 65 on top for extra height, and BTO 12 mid-section for dense blades.

Q2: How long does the zinc coating last?
A2: Heavy galvanizing ≥ 245 g/m² protects steel for 20 – 25 years in normal outdoor settings.

Q3: What tools do I need?
A3: Use high-leverage pliers, stainless steel clips, and portable tensioners.

Q4: Does BMP offer custom coil sizes?
A4: Absolutely. We can wind coils from 300 mm to 1,000 mm OD and adjust clip counts.

Q5: Minimum order?
A5: 50 coils (≈ 500 m). Smaller trial orders remain negotiable.

Conclusion

BTO 12 Razor Wire blends brutal stopping power with long-term economy. BMP crafts each coil from galvanized or stainless steel, aligns blades at 26 mm intervals, and guarantees sharpness out of the box. With proper installation and care, you lock down prisons, military zones, airports, and farms for decades—all at a modest price point. Choose BMP today, and fortify your perimeter with confidence.
