A chain link fence gates are a smart choice for reliable access control. BMP’s gates use tough materials and strong frames. They last long and need little care. Use them in schools, homes, factories, or farms. BMP gives you custom sizes with fast shipping.
| Gate Type | Allowable Clear Width | Required Gate-Post Size | Stiffener Pipe Needed? |
|---|---|---|---|
| Double swing (standard) | ≤ 6 ft per leaf (≤ 12 ft total) | 3 in CS 40 | No |
| Double swing (large) | 6 – 13 ft per leaf (12 – 26 ft total) | 3 ½ in CS 40 | Yes, if leaf ≥ 10 ft |
| Single sliding | 12 ft typical (track type) | 3 ½ in CS 40 | Track + support wheels |
| Frame / Member | Nominal Pipe | Material | Notes |
|---|---|---|---|
| Gate frame | 1 ½ in CS 40 | Galv. steel | Schedule 40 throughout |
| Top rail / braces | 1 ¼ in or 1 ⅝ in CS 40 | Galv. steel | Same spec as rail track |
| Stiffener (leaf ≥ 10 ft) | 1 ¼ in Std. pipe | Galv. steel | Inside gate frame |
| Component | Specification | Spacing / Size |
|---|---|---|
| Chain-link fabric | 9 ga wire, 2 in mesh; knuckled top, twisted-barbed bottom | — |
| Stretcher bars | 3⁄16 in × ¾ in high-carbon steel | Every 12 in on frame/posts |
| Tie wires | 9 ga galvanized | Gate frame 15 in, line post 18 in |
| Bottom tension wire | 7 ga coil-spring steel | Required on all fences |
| Hardware | Material / Size | Function |
|---|---|---|
| Hinges | Heavy-duty malleable iron / steel, 270° swing | Gate rotation |
| Lock device | Combination catch cut-out with padlock provision | Secure closure |
| Truss rods | ⅜ in with turnbuckle (≥ 6 in take-up) | Brace & tension |
| Extension arms (barbed wire) | Steel or malleable iron, 3 wires, 45° incline | Added security |
| Installation Element | Minimum Requirement |
|---|---|
| Line-post spacing | ≤ 10 ft centre-to-centre |
| Pull / corner post | Every 500 ft or angle > 15°; brace both ways |
| Slope post | Needed when grade change > 5% |
| Line-post footing | 12 in Ø × ≈ 3 ft deep concrete |
| Gate-post footing | ≥ 16 in Ø or ≥ 3 × post OD |
| Sliding-gate wheel pad | 15 ft L × 18 in W × 12 in D concrete |
| Fence line-setback | Fence 1 ft inside boundary; extension arm flush |
| Feature | Specification |
|---|---|
| Barbed wire strands | 2 × 12 ½ ga, four-point 14 ga barbs ≤ 5 in apart |
Use this Chain Link Fence Gate when you need visibility and airflow with medium to high security. Ideal where wind load is high. Choose it for places needing easy access with strong locking. Works great for desert, coastal, and urban areas.
“We installed BMP chain link fence gates in our logistics zone. Very durable and secure. No rust after 2 summers. Assembly was quick and clean. Our team recommends BMP.” — Procurement Officer, Durban
Q: Can I add barbed wire on top?
A: Yes, we offer extension arms for 3-strand barbed wire.
Q: Is it suitable for industrial sites?
A: Absolutely. BMP chain link fence gates are designed for heavy-duty use.
Q: Can you customize the size?
A: Yes, we make sizes based on your exact needs.
Q: How long does delivery take?
A: Normally 15–20 days after deposit.
Q: What tools do I need to install it?
A: Basic wrenches, level, and concrete mixer for footing.
BMP’s chain link fence gate gives you proven security, low maintenance, and strong value. With full specs, flexible sizes, and reliable performance, it’s a top choice for commercial and public sites. Contact us today for your custom solution.
