PVC chain link fence is a tough, coated mesh system built to handle harsh weather, high security zones, and public areas. It offers strong corrosion protection, an attractive finish, and easy installation.
What is a PVC Chain Link Fence?
A PVC chain link fence is a standard chain link fence coated with polyvinyl chloride for better durability and appearance. Here’s what defines it:
The typical service life of a PVC chain link fence is:
15 to 25 years, depending on the environment and maintenance.
| Environment | Lifespan |
|---|---|
| Normal Urban Areas | 20–25 years |
| Harsh Coastal Zones | 12–18 years |
| Industrial Sites | 15–20 years |
| Specification Item | Details |
|---|---|
| Product Name | Chain Link Fence |
| Material | Galvanized low carbon steel wire / stainless steel wire / aluminum alloy |
| Surface Finish | Galvanized + PVC Coated |
| Coating Colors | Green (RAL 6005), Black, Brown, White (Custom Available) |
| PVC Coating Type | Extruded, Extruded & Adhered, Fused & Adhered |
| Standard Compliance | ASTM A392, ASTM 567 |
| HS Code | 73144900 |
| Specification Item | Details |
|---|---|
| Wire Diameter Options | 6 GA (4.88 mm), 9 GA (3.66 mm), 11 GA (2.95 mm), 11.5 GA (2.80 mm) |
| Mesh Aperture Sizes | 3/8″, 1/2″, 5/8″, 3/4″, 1″, 1-3/4″, 2″, 2-1/8″ |
| Mesh Configurations | 30×30 mm, 40×40 mm, 50×50 mm, 60×60 mm, 70×70 mm, 80×80 mm, 100×100 mm |
| Selvage Types | Knuckled / Twisted |
| Fence Height Range | 36″ to 144″ (914 mm to 3657 mm) |
| Roll Length Options | 50 ft (15.24 m), 100 ft (30.48 m), or customized |
| Specification Item | Details |
|---|---|
| Breaking Strength | Up to 9650 N (for 6 GA) |
| Zinc Coating Options | 100–610 g/m² (pre or post galvanized) |
| Application Zones | Residential, Commercial, Security, Prison, Airport, Sports Fields, etc. |
| Packaging Method | Woven bags on roll ends, wooden pallet or case (customizable) |
| Estimated Price (FOB) | $2.90 – $6.80 per meter (based on spec and coating type) |
Q: Does PVC last longer than galvanized?
Yes. PVC adds a thick plastic layer that resists rust better in coastal or humid climates.
Q: Can it be used with barbed wire?
Yes. BMP supplies fence brackets for adding top barbed or razor wire.
Q: Is the color coating UV-resistant?
Yes. BMP uses UV-stabilized PVC to stop fading for 10+ years.
Q: Can BMP customize mesh and height?
Absolutely. We produce per your mesh size, gauge, and height needs.
Q: What is the standard PVC Chain Link Fence roll size?
Most orders ship in 50 ft rolls, but 100 ft and custom lengths are also available.
“We use BMP’s PVC chain link fence around logistics yards in Durban. It resists dust, sun, and impact. Color still looks new after two years.”
— Project Manager, Logistics Park, South Africa
PVC chain link fence offers high strength, good looks, and long life. Whether you’re fencing a school, yard, or airport, BMP delivers durable mesh backed by expert service. Select the right mesh size, gauge, and coating for your job. BMP will take care of the rest.
